| Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
| Compressor displacement [cc]: | 155 |
| Compressor ID: | Sd7h15 |
| Compressor oil: | Pag 46 |
| Connecting thread: | 7/8" / 3/4" |
| Features of execution 8: | With PAG compressor oil |
| Id. Cylinder head no. (Compressor): | Kg |
| Manufacturer limitation: | Sanden-equivalent |
| Number of grooves: | 6 |
| Oil quantity [ml]: | 190 |
| Pulley diameter [mm]: | 119 |
| Refrigerant: | R 134a |
| The form: | Round |
| Voltage [V]: | 12 |
| Working voltage [V]: | 12 |
| Compressor ID: | Cvc |
| Compressor oil: | Pag 150 |
| Features of execution 8: | With PAG compressor oil |
| Inlet diameter [mm]: | 20,7, 20.7 |
| Manufacturer limitation: | Delphi-equivalent |
| Number of grooves: | 7 |
| Oil quantity [ml]: | 150 |
| Outlet diameter [mm]: | 14,4, 14.4 |
| Pulley diameter [mm]: | 119 |
| Refrigerant: | R 134a |
| The form: | Oval |
| Voltage [V]: | 12 |
| Working voltage [V]: | 12 |
| Compressor displacement [cc]: | 170 |
| Compressor ID: | 7seu17c |
| Compressor oil: | Pag 46 |
| Features of execution 8: | With PAG compressor oil |
| Inlet diameter [mm]: | 28,4, 28.4 |
| Manufacturer limitation: | Denso-equivalent |
| Number of grooves: | 4 |
| Oil quantity [ml]: | 180 |
| Outlet diameter [mm]: | 15,3, 15.3 |
| Pulley diameter [mm]: | 100 |
| Refrigerant: | R 134a |
| The form: | Oval |
| Voltage [V]: | 12 |
| Working voltage [V]: | 12 |
| Belt pulley: | with ribbed V-belt pulley |
| Compressor displacement [cc]: | 160 |
| Compressor ID: | Pxe16 |
| Inlet diameter [mm]: | 26,4 |
| Number of grooves: | 5 |
| Outlet diameter [mm]: | 15,3 |
| Pulley diameter [mm]: | 127 |
| Refrigerant: | R 134a |
| Voltage [V]: | 12 |
| Compressor oil: | Pag 46 |
| Manufacturer limitation: | Valeo/zexel dcs17ecr |
| Number of fixing holes: | 3 |
| Number of grooves: | 7 |
| Number of ribs: | 7 |
| Oil quantity [ml]: | 210, 220 |
| Pulley diameter [mm]: | 115 |
| Refrigerant: | R 134a |
| Valve type: | Solenoid valve |
| Compressor displacement [cc]: | 86 |
| Compressor ID: | Sc90v, Vs-90 |
| Compressor oil: | Pag 46 |
| Features of version 2: | O-rings included, Prefilled pag-oil, With short bracket |
| Inlet diameter [mm]: | 16.4 |
| Manufacturer limitation: | Visteon |
| Number of grooves: | 6 |
| Number of poles: | 2 |
| Oil quantity [ml]: | 120 |
| Outlet diameter [mm]: | 13.2 |
| Pulley diameter [mm]: | 95 |
| Refrigerant: | R 134a |
| Specification: | Mounting brack. 91mm |
| Voltage [V]: | 12 |
| Working voltage [V]: | 12 |
| Compressor oil: | Pag 46 |
| Manufacturer limitation: | Harrison cvc5 |
| Number of fixing holes: | 3 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Oil quantity [ml]: | 150 |
| Pulley diameter [mm]: | 115 |
| Refrigerant: | R 134a |
| Compressor displacement [cc]: | 165 |
| Compressor ID: | 7SB17 |
| Manufacturer limitation: | 7sbu16c447170635044 |
| Number of grooves: | 4 |
| Oil quantity [ml]: | 170 |
| Pulley diameter [mm]: | 120 |
| Refrigerant: | R 134a |
| Voltage [V]: | 12 |
| Volume [ml]: | 245 |
| Weight, kg]: | 7.3 |
| Compressor oil: | Pag 46 |
| Manufacturer limitation: | Zexel dks17d |
| Number of fixing holes: | 4 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Oil quantity [ml]: | 180 |
| Pulley diameter [mm]: | 119 |
| Refrigerant: | R 134a |
| Compressor oil: | Pag 46 |
| Manufacturer limitation: | Sanden sd7v16 |
| Number of fixing holes: | 3 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Oil quantity [ml]: | 135 |
| Pulley diameter [mm]: | 120 |
| Refrigerant: | R 134a |
| Inlet diameter [mm]: | 21,6, 21.6 |
| Manufacturer limitation: | Harrison/delphi v5 |
| Number of fixing holes: | 3 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Oil quantity [ml]: | 265 |
| Outlet diameter [mm]: | 15,2, 15.2 |
| Pulley diameter [mm]: | 120, 125 |
| Refrigerant: | R 134a |
| Compressor displacement [cc]: | 150 |
| Compressor ID: | Hcc-hs15 |
| Number of grooves: | 4 |
| Oil quantity [ml]: | 120 |
| Pulley diameter [mm]: | 133 |
| Refrigerant: | R 134a |
| Voltage [V]: | 12 |
| Additional Information: | With o-ring |
| Belt pulley: | with ribbed V-belt pulley |
| Compressor ID: | V5 |
| Manufacturer limitation: | Delphi, Harrison |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Packing height [cm]: | 21.5 |
| Packing length [cm]: | 28 |
| Packing width [cm]: | 18.5 |
| Pulley diameter [mm]: | 126 |
| Rated voltage [V]: | 12 |
| Refrigerant: | R 134a |
| Voltage [V]: | 12 |
| Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
| Compressor displacement [cc]: | 122.8 |
| Compressor ID: | Sd6v12 |
| Compressor oil: | Pag 46 |
| Features of execution 5: | Easy fit |
| Features of execution 8: | With PAG compressor oil |
| Id. Cylinder head no. (Compressor): | Vfd |
| Inlet diameter [mm]: | 16,4, 16.4 |
| Manufacturer limitation: | Sanden-equivalent |
| Number of grooves: | 6 |
| Oil quantity [ml]: | 135 |
| Outlet diameter [mm]: | 16,4, 16.4 |
| Pulley diameter [mm]: | 119 |
| Refrigerant: | R 134a |
| The form: | Square |
| Voltage [V]: | 12 |
| Working voltage [V]: | 12 |
| Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
| Manufacturer limitation: | Pv6 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Compressor oil: | Pag 46 |
| Manufacturer limitation: | Sanden sd6v12 |
| Number of fixing holes: | 3 |
| Number of grooves: | 5 |
| Number of ribs: | 5 |
| Oil quantity [ml]: | 120, 125 |
| Pulley diameter [mm]: | 125 |
| Refrigerant: | R 134a |
