Compressor ID: | 10pa, 7sb / 7sbu |
Outside diameter [mm]: | 96.4 |
Working voltage [V]: | 12 |
Compressor ID: | 10pa17c |
Compressor displacement [cc]: | 170 |
Compressor oil: | Pag 46 |
Features of execution 8: | With PAG compressor oil |
Manufacturer limitation: | Denso-equivalent |
Number of grooves: | 6 |
Oil quantity [ml]: | 180 |
Pulley diameter [mm]: | 129 |
Refrigerant: | R 134a |
The form: | Square |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 10s17c |
Compressor displacement [cc]: | 177 |
Compressor oil: | Pag 46 |
Features of execution 8: | without sensor |
Features of version 2: | O-rings included, Prefilled pag-oil |
Manufacturer limitation: | Denso |
Mount type: | Four-point mount |
Number of grooves: | 4 |
Oil quantity [ml]: | 180, 200 |
Pulley diameter [mm]: | 130 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 10pa17c |
Compressor displacement [cc]: | 177, 178 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Manufacturer limitation: | Denso |
Number of grooves: | 6 |
Number of poles: | 1 |
Oil quantity [ml]: | 150, 200 |
Pulley diameter [mm]: | 130 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Voltage from [V]: | 12 |
Additional Information: | With o-ring |
Belt pulley: | with ribbed V-belt pulley |
Compressor ID: | 10pa17j |
Manufacturer limitation: | Denso |
Number of grooves: | 6 |
Number of ribs: | 6 |
Packing height [cm]: | 21.5 |
Packing length [cm]: | 28 |
Packing width [cm]: | 18.5 |
Pulley diameter [mm]: | 126 |
Rated voltage [V]: | 12 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Additional Information: | With gasket |
Belt pulley: | with ribbed V-belt pulley |
Compressor ID: | 10pa17c |
Manufacturer limitation: | Denso |
Number of grooves: | 6 |
Number of ribs: | 6 |
Packing height [cm]: | 24 |
Packing length [cm]: | 27.5 |
Packing width [cm]: | 18.5 |
Pulley diameter [mm]: | 136 |
Rated voltage [V]: | 12 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
Compressor ID: | 5se12c |
Compressor displacement [cc]: | 120 |
Compressor oil: | Pag 46 |
Features of execution 8: | With PAG compressor oil |
Inlet diameter [mm]: | 18,3, 18.3 |
Manufacturer limitation: | Denso-equivalent |
Number of grooves: | 6 |
Oil quantity [ml]: | 120, 160 |
Outlet diameter [mm]: | 15,5, 15.5 |
Pulley diameter [mm]: | 100 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 5se12c |
Compressor displacement [cc]: | 120 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Inlet diameter [mm]: | 18.3 |
Manufacturer limitation: | Denso |
Mount type: | Three-point mount |
Number of grooves: | 6 |
Oil quantity [ml]: | 100 |
Outlet diameter [mm]: | 15.5 |
Pulley diameter [mm]: | 100 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 10s17c |
Compressor displacement [cc]: | 188 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Manufacturer limitation: | Denso |
Number of grooves: | 6 |
Oil quantity [ml]: | 150 |
Pulley diameter [mm]: | 130 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 10s20h |
Compressor displacement [cc]: | 210 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Inlet diameter [mm]: | 18.3 |
Manufacturer limitation: | Denso |
Mount type: | Four-point mount |
Number of grooves: | 6 |
Oil quantity [ml]: | 230 |
Outlet diameter [mm]: | 15.5 |
Pulley diameter [mm]: | 130 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Belt pulley: | Multi-ribbed belt pulley, With multi-ribbed pulley |
Compressor ID: | Dks17ds |
Compressor displacement [cc]: | 170 |
Compressor oil: | Pag 100 |
Features of execution 8: | With PAG compressor oil |
Manufacturer limitation: | Zexel-equivalent |
Number of grooves: | 6 |
Oil quantity [ml]: | 150 |
Pulley diameter [mm]: | 119 |
Refrigerant: | R 134a |
The form: | Oval |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor ID: | 10sr17c |
Compressor displacement [cc]: | 188 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Manufacturer limitation: | Denso |
Number of grooves: | 6 |
Oil quantity [ml]: | 160 |
Pulley diameter [mm]: | 110, 115 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Belt pulley: | with ribbed V-belt pulley |
Build type: | Fixed with bolts / screws |
Compressor ID: | 6seu16c |
Compressor displacement [cc]: | 160 |
Inlet diameter [mm]: | 18,3 |
Number of grooves: | 6 |
Outlet diameter [mm]: | 15,5 |
Pulley diameter [mm]: | 120 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Compressor ID: | 6seu16c |
Compressor displacement [cc]: | 160 |
Compressor oil: | Pag 46 |
Features of version 2: | O-rings included, Prefilled pag-oil |
Manufacturer limitation: | Denso |
Mount type: | Three-point mount |
Number of grooves: | 6 |
Number of poles: | 2 |
Oil quantity [ml]: | 150 |
Pulley diameter [mm]: | 120 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Working voltage [V]: | 12 |
Compressor oil: | Pag 46 |
Manufacturer limitation: | Denso 10pa17c |
Number of fixing holes: | 4 |
Oil quantity [ml]: | 180 |
Pulley diameter [mm]: | 115 |
Refrigerant: | R 134a |
Build type: | Flange mount |
Compressor ID: | 10pa17c |
Manufacturer limitation: | Denso |
Packing height [cm]: | 25 |
Packing length [cm]: | 27.5 |
Packing width [cm]: | 19.5 |
Pulley diameter [mm]: | 116 |
Rated voltage [V]: | 12 |
Refrigerant: | R 134a |
Voltage [V]: | 12 |
Weight, kg]: | 5.07 |
