Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Chamfer diameter 1 [mm]: | 75 |
Chamfer diameter 2 [mm]: | 75 |
Diameter [mm]: | 324 |
Height [mm]: | 61,2, 61.2 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Part type: | Brake disc |
check value: | Approved, Ece r90 approved |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Location: | Rear axle |
Location in the car: | Left, Right |
Manufacturing material: | Table casting |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Coated, Oiled |
Thickness [mm]: | 68 mm |
Weight, kg]: | 5.25 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Diameter [mm]: | 300 |
Features of execution 8: | With screws |
Height [mm]: | 68,1, 68.1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Thickness [mm]: | 10 mm |
Treatment: | High carbon |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Diameter [mm]: | 324 |
Features of execution 8: | With screws |
Height [mm]: | 61,1, 61.1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Part type: | Brake disc |
Tightening torque [Nm]: | 8.5 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Chamfer diameter 1 [mm]: | 98 |
Diameter [mm]: | 284 |
Height [mm]: | 39,5, 39.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 20.2 |
Number of holes in the wheel rim: | 4 holes |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 284 |
Part type: | Brake disc |
Surface: | Varnished |
Treatment: | High carbon |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 79 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 302 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 76, 76.1 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 20.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 302 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Treatment: | High carbon |
Weight, kg]: | 7.65 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 302 |
Height [mm]: | 76,2, 76.2 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 20.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 302 |
Part type: | Brake disc |
Arrangement / number of holes: | 05/06 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 79 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 324 |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 67 |
Location: | Rear axle |
Minimum thickness [mm]: | 18.4 |
Outside diameter [mm]: | 324 |
Surface: | Varnished |
Technical information: | 98200 1231 0 1 |
Weight, kg]: | 7.8 |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Diameter [mm]: | 324 |
Features of execution 8: | With screws |
Height [mm]: | 61,1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Part type: | Brake disc |
Treatment: | High carbon |
Wheel hub diameter [mm]: | 75 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Height [mm]: | 68 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Required amount: | 2 |
Wheel bolt hole diameter [mm]: | 14.5 °C |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Diameter [mm]: | 300 |
Height [mm]: | 68,5, 68.5 |
Hub diameter 1 [mm]: | 75 |
Hub diameter [mm]: | 75 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.4 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Weight, kg]: | 5.25, 5.37 |
Additional Information: | Without hub, Without wheel axle |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 324 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 61,1, 61.1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Packing height [cm]: | 14 |
Packing length [cm]: | 36.5 |
Packing width [cm]: | 35 |
Part type: | Brake disc |
Technical information: | 98200 0584 0 1 |
Weight, kg]: | 6,5, 6.7 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 300 |
Height [mm]: | 68,5, 68.5 |
Hub diameter 1 [mm]: | 75 |
Hub diameter [mm]: | 75 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Weight, kg]: | 5,8, 5,9 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 79 |
Diameter [mm]: | 302 |
Features of execution 8: | With screws |
Height [mm]: | 76,1, 76.1 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 302 |
Part type: | Brake disc |
Thickness [mm]: | 28 mm |
Treatment: | High carbon |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 79 |
Diameter [mm]: | 302 |
Features of execution 8: | With screws |
Height [mm]: | 76,1, 76.1 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 20.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 302 |
Part type: | Brake disc |
Thickness [mm]: | 22 mm |
Treatment: | High carbon |
Wear sensor: | With wear sensor, incl. wear gauge |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Height [mm]: | 67,9, 67.9 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Required amount: | 2 |
Wheel bolt hole diameter [mm]: | 14.5 °C |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Location: | Rear axle |
Location in the car: | Left, Right |
Manufacturing material: | Table casting |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Coated, Oiled |
Thickness [mm]: | 68.5 mm |
Weight, kg]: | 5.67 |
Additional Information: | Without hub, Without wheel axle |
Arrangement / number of holes: | 05/06, 05/07 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Diameter [mm]: | 300 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 68,1, 68.1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 300 |
Packing height [cm]: | 15.5 |
Packing length [cm]: | 33 |
Packing width [cm]: | 31.5 |
Part type: | Brake disc |
Technical information: | 98200 0426 0 1 |
Weight, kg]: | 5.1 |
Additional Information: | With screws |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Diameter [mm]: | 324 |
Features of execution 8: | With screws |
For article or original number: | 08.5580.11 |
Height [mm]: | 61, 61,1, 61.1 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Part type: | Brake disc |
Surface: | Coated |
Tightening torque [Nm]: | 120 |
Treatment: | High carbon |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 75 |
Chamfer diameter 1 [mm]: | 120 |
Chamfer diameter 2 [mm]: | 120 |
Location: | Rear axle |
Location in the car: | Left, Right |
Manufacturing material: | Table casting |
Minimum thickness [mm]: | 10.4 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 324 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Coated, Oiled |
Thickness [mm]: | 61.5 mm |
Weight, kg]: | 6.6 |
