Brake disc type: | Ventilated |
Location: | Front axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Chamfer diameter 1 [mm]: | 98 |
Diameter [mm]: | 257.5 |
Height [mm]: | 40,5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Surface: | Varnished |
Weight, kg]: | 4,9 |
Wheel hub diameter [mm]: | 59 |
Brake disc type: | Ventilated |
Location: | Front axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Brake system: | Bendix |
Centering diameter [mm]: | 59 |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Diameter [mm]: | 257 |
Height [mm]: | 40,5, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Thickness [mm]: | 20 mm |
Wear sensor: | With wear sensor, incl. wear gauge, with integrated wear warning contact |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Chamfer diameter 1 [mm]: | 98 |
Chamfer diameter 2 [mm]: | 98 |
Diameter [mm]: | 257.5 |
Height [mm]: | 40,5, 40.5 |
Hole diameter [mm]: | 16.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257.5 |
Part type: | Brake disc |
Required amount: | 2 |
Treatment: | Alloyed / High Carbon |
unit of measurement: | Piece |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Diameter [mm]: | 257 |
Height [mm]: | 40,5, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Weight, kg]: | 4.82 |
check value: | K.B.A.: 61209 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Height [mm]: | 28 |
Location: | Rear axle |
Minimum thickness [mm]: | 10 |
Outside diameter [mm]: | 272 |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 14 |
Brake disc type: | Full |
Centering diameter [mm]: | 71 |
Chamfer diameter 1 [mm]: | 108 |
Chamfer diameter 2 [mm]: | 108 |
Diameter [mm]: | 290 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 49 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 12, 13 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 290 |
Part type: | Brake disc |
Surface: | Varnished |
Treatment: | High carbon |
Weight, kg]: | 5.72 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Diameter [mm]: | 290 |
Height [mm]: | 35 |
Hub diameter 1 [mm]: | 70.8 |
Hub diameter [mm]: | 71 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 290 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 4.78, 5 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 98 |
Chamfer diameter 2 [mm]: | 98 |
Diameter [mm]: | 257 |
Height [mm]: | 40,5, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Brake system: | Bendix |
Centering diameter [mm]: | 59 |
Diameter [mm]: | 257 |
For article or original number: | L2055v |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Brake system: | Bendix |
Chamfer diameter 1 [mm]: | 59 |
Chamfer diameter 2 [mm]: | 59 |
Diameter [mm]: | 257 |
Height [mm]: | 40,5, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
check value: | Approved, Ece r90 approved |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Chamfer diameter 1 [mm]: | 98 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of fixing holes: | 1 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257, 257.5 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Coated |
Weight, kg]: | 4,9, 4.85 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59.02 |
Chamfer diameter 1 [mm]: | 98 |
Diameter [mm]: | 257.5 |
Height [mm]: | 40,5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257.5 |
Part type: | Brake disc |
Surface: | Oiled |
Wheel hub diameter [mm]: | 59 |
complies with EEC standards: | E1 90r-02c0339/1101, ECE-R90 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 71, 71.07 |
Diameter [mm]: | 290 |
Height [mm]: | 35 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 290 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Treatment: | Untreated |
check value: | E4 90 R - 02 C0703/2 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 59 |
Chamfer diameter 2 [mm]: | 59 |
Diameter [mm]: | 257 |
Height [mm]: | 40,5, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18 |
Number of holes: | 4, 5 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 59 |
Depth [mm]: | 40.5 |
Diameter [mm]: | 257 |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 18, 18.2 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Surface: | Oiled |
Treatment: | Untreated |
check value: | E1 90R-02C0339/1831 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 59 |
Diameter [mm]: | 257, 257.5 |
Height [mm]: | 40, 40.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Number of mounting holes: | 5 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 71.07 |
Chamfer diameter 1 [mm]: | 108 |
Location: | Rear axle |
Minimum thickness [mm]: | 10 |
Number of fixing holes: | 3 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 290 |
Surface: | Coated |
Weight, kg]: | 4.91 |
Follow these steps to find exactly what you need:
Remember to input your information carefully when ordering from the “Brake rotor” category for Citroen Jumpy on EXIST.AE.
You can receive your Brake discs for Citroen Jumpy by FedEx air parcel. Shopping at EXIST.AE is straightforward and user-friendly. We prioritise your satisfaction and ensure the quality of our automotive parts and products. Experience the difference yourself!
