Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 63,5 |
Height [mm]: | 39,9 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 278 |
Surface: | Varnished |
check value: | Approved |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Diameter [mm]: | 278 |
Height [mm]: | 40 |
Hub diameter 1 [mm]: | 63.5 |
Hub diameter [mm]: | 63.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of holes in the wheel rim: | 4, 4 holes |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 6,5, 6.6 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 63.5, 64 |
Diameter [mm]: | 278 |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Treatment: | Untreated |
check value: | E1 90R-02C0074/1474 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Location: | Front axle |
Minimum thickness [mm]: | 23 |
Number of holes in the wheel rim: | 4 |
Outside diameter [mm]: | 278 |
Surface: | Coated |
Weight, kg]: | 6.78 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Diameter [mm]: | 278 |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278.3 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Treatment: | High carbon |
Wheel hub diameter [mm]: | 63.6 |
complies with EEC standards: | ECE-R90 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 63.5 |
Height [mm]: | 39,8 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of holes in the wheel rim: | 4 |
Outside diameter [mm]: | 278 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Chamfer diameter 2 [mm]: | 108 |
Height [mm]: | 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Galvanized |
Arrangement / number of holes: | 04/04 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 39,6 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 300 |
Packing height [cm]: | 9.5 |
Packing length [cm]: | 33.5 |
Packing width [cm]: | 32 |
Surface: | Coated |
Weight, kg]: | 7.8 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Diameter [mm]: | 278 |
Height [mm]: | 39,9, 39.9 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Weight, kg]: | 6.6 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Diameter [mm]: | 278 |
Height [mm]: | 39,9, 39.9 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Weight, kg]: | 6.6 |
Location: | Front axle, Rear axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5, 64 |
Diameter [mm]: | 278 |
Height [mm]: | 39,7, 40 |
Location: | Front axle |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Surface: | Coated |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Chamfer diameter 1 [mm]: | 108 |
Chamfer diameter 2 [mm]: | 108 |
Diameter [mm]: | 278 |
Height [mm]: | 39,8, 39.8 |
Hole diameter [mm]: | 14 |
Inner diameter [mm]: | 136.2 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Part type: | Brake disc |
Surface: | Coated |
Arrangement / number of holes: | 04/04 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 39,6 |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 300 |
Surface: | Coated |
Weight, kg]: | 7.8 |
Location: | Front axle, Rear axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Additional Information: | Without hub, Without wheel axle |
Arrangement / number of holes: | 04/04 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 63.6 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 39,6 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 300 |
Packing height [cm]: | 9.5 |
Packing length [cm]: | 33.5 |
Packing width [cm]: | 32 |
Surface: | Coated |
Weight, kg]: | 7.8 |
Additional Information: | Without hub, Without wheel axle |
Arrangement / number of holes: | 04/04 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Chamfer diameter 1 [mm]: | 108 |
Chamfer diameter 2 [mm]: | 108 |
Diameter [mm]: | 278 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 39,9, 40 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Packing height [cm]: | 10 |
Packing length [cm]: | 31.5 |
Packing width [cm]: | 30 |
Part type: | Brake disc |
Surface: | Coated |
Technical information: | 98200 2790 0 1 pro |
Weight, kg]: | 6,5 |
Arrangement / number of holes: | 04/04 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 39,9 |
Location: | Front axle |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 278 |
Surface: | Coated |
Weight, kg]: | 6,5 |
Additional Information: | Without ABS sensor ring |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 39,9 |
Minimum thickness [mm]: | 23 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 278 |
Package quantity [pcs]: | 2 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 63.5 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 40 |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 278 |
Packing height [cm]: | 8.5 |
Packing length [cm]: | 28 |
Packing width [cm]: | 28 |
Surface: | Coated |
Weight, kg]: | 13.35 |
