Bolt head profile: | Internal torx |
Length [mm]: | 12 |
Location in the car: | Left, Right |
Outside thread [mm]: | M8 x 1 |
Part type: | Brake disc mounting elements |
Spanner jaw width: | T30 |
Surface: | Galvanized |
Weight, kg]: | 0.004 |
Location: | Rear axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Brake disc thickness [mm]: | 18 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 65 |
Depth [mm]: | 34.9 |
Diameter [mm]: | 239 |
Features of execution 8: | With screws |
Height [mm]: | 35 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 16 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Oiled |
Treatment: | Untreated |
Brake disc thickness [mm]: | 18 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 65 |
Depth [mm]: | 34.9 |
Diameter [mm]: | 239 |
Height [mm]: | 34,90 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 16 |
Number of holes: | 5 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 238.7 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 9.6 |
Brake disc type: | Full |
Centering diameter [mm]: | 68 |
Chamfer diameter 1 [mm]: | 68 |
Chamfer diameter 2 [mm]: | 68 |
Diameter [mm]: | 281 |
Features of execution 8: | With screws |
Height [mm]: | 73,2, 73.2 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 281 |
Part type: | Brake disc |
Thickness [mm]: | 9.6 mm |
Type of admission: | With general authorization to operate (abe) |
Wear sensor: | With wear sensor, with integrated wear warning contact |
Brake disc thickness [mm]: | 16 |
Brake disc type: | Full |
Centering diameter [mm]: | 85 |
Diameter [mm]: | 272 |
Features of execution 8: | With screws |
Height [mm]: | 96.5 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 14 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 272 |
Part type: | Brake disc |
Thickness [mm]: | 68 W |
Treatment: | High carbon |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 130 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Outside diameter [mm]: | 276 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 16 |
Brake disc type: | Full |
Centering diameter [mm]: | 85 |
Diameter [mm]: | 272 |
Height [mm]: | 96,5, 96.5 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 14 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 272 |
Part type: | Brake disc |
Weight, kg]: | 6.98 |
check value: | K.B.A.: 61210 |
Brake disc thickness [mm]: | 21.9, 22 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 65 |
Depth [mm]: | 36.58 |
Diameter [mm]: | 256 |
Height [mm]: | 36,50 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of holes: | 5 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 256 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 21.9, 22 |
Brake disc type: | Ventilated |
Build type: | Fixed with bolts / screws |
Centering diameter [mm]: | 65 |
Depth [mm]: | 36.58 |
Diameter [mm]: | 256 |
Features of execution 8: | With screws |
Height [mm]: | 37 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 256 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Treatment: | Untreated |
check value: | E1*90R02/06/C*0141/0 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 85 |
Height [mm]: | 77 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Outside diameter [mm]: | 276 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 85 |
Diameter [mm]: | 258 |
Height [mm]: | 96,5, 96.5 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 258 |
Part type: | Brake disc |
Weight, kg]: | 6,2 |
check value: | K.B.A.: 61210 |
Brake disc thickness [mm]: | 16 |
Brake disc type: | Full |
Centering diameter [mm]: | 88 |
Diameter [mm]: | 280 |
Height [mm]: | 78,6, 78.6 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 13 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 280 |
Part type: | Brake disc |
Thickness [mm]: | 68 W |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 85 |
Diameter [mm]: | 276 |
Features of execution 8: | With screws |
Height [mm]: | 77 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 276 |
Part type: | Brake disc |
Thickness [mm]: | 22 mm |
Treatment: | High carbon |
Wear sensor: | With wear sensor, incl. wear gauge |
Brake disc thickness [mm]: | 16.3 |
Brake disc type: | Full |
Chamfer diameter 1 [mm]: | 130 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 14 |
Outside diameter [mm]: | 298 |
Part type: | Brake disc |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 85 |
Chamfer diameter 1 [mm]: | 130 |
Chamfer diameter 2 [mm]: | 130 |
Diameter [mm]: | 258 |
Features of execution: | Without wheel bearing |
Features of execution 8: | Without hub, Without wheel axle |
Height [mm]: | 96.5, 97 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 258 |
Part type: | Brake disc |
Surface: | Coated, Varnished |
Weight, kg]: | 6.14 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 130 |
Chamfer diameter 2 [mm]: | 130 |
Diameter [mm]: | 275.5 |
Height [mm]: | 75 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 276 |
Part type: | Brake disc |
Brake disc thickness [mm]: | 26 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 70 |
Chamfer diameter 1 [mm]: | 96 |
Height [mm]: | 70 |
Location: | Front axle |
Minimum thickness [mm]: | 23 |
Outside diameter [mm]: | 290 |
Surface: | Varnished |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 85 |
Chamfer diameter 1 [mm]: | 130 |
Diameter [mm]: | 276 |
Features of execution 8: | With screws |
Height [mm]: | 77 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 276 |
Part type: | Brake disc |
Surface: | Varnished |
Treatment: | High carbon |
Weight, kg]: | 6.45 |
Wheel hub diameter [mm]: | 85 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 85 |
Diameter [mm]: | 276 |
Height [mm]: | 77 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 276 |
Part type: | Brake disc |
Weight, kg]: | 6.67 |
check value: | K.B.A.: 61209 |
Follow these steps to find exactly what you need:
Remember to input your information carefully when ordering from the “Brake rotor” category for Mercedes Sprinter on EXIST.AE.
You can receive your Brake discs for Mercedes Sprinter by FedEx air parcel. Shopping at EXIST.AE is straightforward and user-friendly. We prioritise your satisfaction and ensure the quality of our automotive parts and products. Experience the difference yourself!
