Brake disc thickness [mm]: | 20.5 |
Brake disc type: | Ventilated |
Chamfer diameter 2 [mm]: | 126 |
Diameter [mm]: | 282 |
Height [mm]: | 35 |
Hub diameter 1 [mm]: | 107 |
Hub diameter [mm]: | 107 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19.1 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 282 |
Part type: | Brake disc |
Weight, kg]: | 5.1, 5.2 |
Brake disc thickness [mm]: | 21 |
Brake disc type: | Ventilated |
Location: | Front axle |
Location in the car: | Left, Right |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 283 |
Part type: | Brake disc |
Required amount: | 2 |
Surface: | Coated |
Weight, kg]: | 5.025 |
Brake disc thickness [mm]: | 20.3 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 107 |
Chamfer diameter 1 [mm]: | 126 |
Chamfer diameter 2 [mm]: | 126 |
Colour: | Black |
Diameter [mm]: | 282 |
Height [mm]: | 35,2, 35.2 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19.1 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 282 |
Part type: | Brake disc |
Surface: | Varnished |
Brake disc thickness [mm]: | 20.4 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 107 |
Chamfer diameter 1 [mm]: | 126 |
Diameter [mm]: | 282.5 |
Height [mm]: | 35,2, 35.2 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19.1 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 282.5 |
Part type: | Brake disc |
Surface: | Oiled |
Treatment: | Alloyed / High Carbon, High carbon |
Wheel hub diameter [mm]: | 107 |
complies with EEC standards: | ECE-R90 |
Brake disc thickness [mm]: | 20 |
Brake disc type: | Ventilated, With internal ventilation |
Location: | Rear axle |
Location in the car: | Left, Right |
Outside diameter [mm]: | 290 |
Surface: | Coated |
Brake disc thickness [mm]: | 20.4 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 107 |
Diameter [mm]: | 282 |
For article or original number: | 09.5782.10 |
Height [mm]: | 35, 35,2, 35.2 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19.1 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 282 |
Part type: | Brake disc |
Tightening torque [Nm]: | 130 |
Treatment: | High carbon |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Chamfer diameter 2 [mm]: | 130 |
Diameter [mm]: | 298 |
Height [mm]: | 80 |
Hub diameter 1 [mm]: | 103 |
Hub diameter [mm]: | 103 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 298 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 7.84, 7.94 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 299 |
Height [mm]: | 66 |
Hub diameter 1 [mm]: | 103 |
Hub diameter [mm]: | 103 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 299 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 6.28, 6.42 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 299 |
Height [mm]: | 75 |
Hub diameter 1 [mm]: | 98 |
Hub diameter [mm]: | 98 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 299 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 6.53, 6.66 |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Perforated, Ventilated |
Chamfer diameter 2 [mm]: | 130 |
Diameter [mm]: | 304 |
Height [mm]: | 72 |
Hub diameter 1 [mm]: | 103 |
Hub diameter [mm]: | 103 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 30 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 304 |
Paired article numbers: | 16490 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 8,4, 8.26 |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Perforated, Ventilated |
Chamfer diameter 2 [mm]: | 130 |
Diameter [mm]: | 304 |
Height [mm]: | 72 |
Hub diameter 1 [mm]: | 103 |
Hub diameter [mm]: | 103 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 30 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 304 |
Paired article numbers: | 16491 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 8,4, 8.26 |
Brake disc thickness [mm]: | 20.5 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 107 |
Chamfer diameter 1 [mm]: | 126 |
Chamfer diameter 2 [mm]: | 126 |
Diameter [mm]: | 282.5 |
Height [mm]: | 35,3, 35.3 |
Hole diameter [mm]: | 8.4 |
Inner diameter [mm]: | 145 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19.1 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 282.5 |
Part type: | Brake disc |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
check value: | E1 90R-02C0115/0416 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 103 |
Chamfer diameter 1 [mm]: | 130 |
Chamfer diameter 2 [mm]: | 130 |
Colour: | Black |
Diameter [mm]: | 299 |
Drum diameter: | 180 |
Height [mm]: | 99,9, 99.9 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 299 |
Part type: | Brake disc |
Surface: | Varnished |
check value: | E1 90R-02 C0226/0199 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 319 |
Height [mm]: | 67 |
Hub diameter 1 [mm]: | 98 |
Hub diameter [mm]: | 98 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 319 |
Paired article numbers: | 17071 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 8.6, 8.96 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 98 |
Chamfer diameter 1 [mm]: | 130 |
Chamfer diameter 2 [mm]: | 130 |
Colour: | Black |
Diameter [mm]: | 299 |
Height [mm]: | 67 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 299 |
Part type: | Brake disc |
Surface: | Varnished |
Thread size: | 15.4 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 330 |
Height [mm]: | 75 |
Hub diameter 1 [mm]: | 98 |
Hub diameter [mm]: | 98 |
Location: | Rear axle |
Location in the car: | Left |
Minimum thickness [mm]: | 26 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 330 |
Paired article numbers: | 17703 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 9.22, 9.4 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 330 |
Height [mm]: | 75 |
Hub diameter 1 [mm]: | 98 |
Hub diameter [mm]: | 98 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 330 |
Paired article numbers: | 17702 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 9.22, 9.4 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 103 |
Chamfer diameter 1 [mm]: | 130 |
Chamfer diameter 2 [mm]: | 130 |
Colour: | Black |
Diameter [mm]: | 298 |
Height [mm]: | 65 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 298 |
Part type: | Brake disc |
Surface: | Varnished |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 103 |
Chamfer diameter 1 [mm]: | 136 |
Chamfer diameter 2 [mm]: | 136 |
Colour: | Black |
Diameter [mm]: | 297 |
Height [mm]: | 80,1, 80.1 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 297 |
Part type: | Brake disc |
Surface: | Varnished |
check value: | E1 90R-02 C0176/0492 |
Brake disc thickness [mm]: | 34 |
Brake disc type: | Perforated, Ventilated |
Diameter [mm]: | 330 |
Height [mm]: | 69,5, 69.5 |
Hub diameter 1 [mm]: | 98 |
Hub diameter [mm]: | 98 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 32 |
Number of holes in the wheel rim: | 5, 5 holes |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 330 |
Paired article numbers: | 17700 |
Part type: | Brake disc |
Surface: | Coated |
Weight, kg]: | 10.74, 10.98 |
