Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Height [mm]: | 34 |
Minimum thickness [mm]: | 8 |
Outside diameter [mm]: | 270 |
Surface: | Coated |
Treatment: | Untreated |
check value: | E1*90R02/06/C*0250/1 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7.5 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 270 |
Surface: | Coated |
Weight, kg]: | 3 |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 47,4 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.5 |
Outside diameter [mm]: | 274 |
Packing height [cm]: | 12 |
Packing length [cm]: | 33 |
Packing width [cm]: | 31.5 |
Surface: | Coated |
Weight, kg]: | 4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Height [mm]: | 47 |
Minimum thickness [mm]: | 8 |
Outside diameter [mm]: | 274 |
Surface: | Coated |
Treatment: | Untreated |
check value: | E1*90R02/05/C*0250/1 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Diameter [mm]: | 259 |
Height [mm]: | 30,5 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7.5 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 259 |
Part type: | Brake disc |
Surface: | Oiled |
Wheel hub diameter [mm]: | 62 |
complies with EEC standards: | E1 90r-02c0100/0323, ECE-R90 |
Arrangement / number of holes: | 7/5 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 55 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 30, 30.3 |
Hub bore diameter [mm]: | 55 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7.5 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 7 |
Outside diameter [mm]: | 259 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 9 mm |
Weight, kg]: | 3,1 |
check value: | Ece r90 approved |
Additional Information: | Without hub, Without wheel axle |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 47,4 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.5 |
Outside diameter [mm]: | 274 |
Packing height [cm]: | 12 |
Packing length [cm]: | 33 |
Packing width [cm]: | 31.5 |
Surface: | Coated |
Weight, kg]: | 4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 55 |
Chamfer diameter 1 [mm]: | 100 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8.5 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 265 |
Surface: | Coated |
Weight, kg]: | 3,6 |
Arrangement / number of holes: | 05/07 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 46 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Outside diameter [mm]: | 282 |
Packing height [cm]: | 12 |
Packing length [cm]: | 33 |
Packing width [cm]: | 31.5 |
Surface: | Coated |
Weight, kg]: | 6.9 |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 46 |
Location: | Front axle |
Location in the car: | Left, Right |
Outside diameter [mm]: | 282 |
Surface: | Coated |
check value: | R90 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Height [mm]: | 49,5 |
Hub diameter [mm]: | 62 |
Minimum thickness [mm]: | 26 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 298.5 |
Surface: | Coated |
Weight, kg]: | 8.41 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 62 |
Height [mm]: | 49,3 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 25 |
Outside diameter [mm]: | 298 |
Surface: | Varnished |
check value: | Approved |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated |
Height [mm]: | 46 |
Hub diameter [mm]: | 62 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 23 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 282 |
Surface: | Coated |
Weight, kg]: | 6.85 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Chamfer diameter 1 [mm]: | 62 |
Height [mm]: | 49,3 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 25 |
Outside diameter [mm]: | 298 |
Surface: | Varnished |
check value: | Approved |
Arrangement / number of holes: | 7/5 |
Brake disc thickness [mm]: | 22 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 55 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 46, 46.2 |
Hub bore diameter [mm]: | 55 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 19 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 7 |
Outside diameter [mm]: | 275 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 22 mm |
Weight, kg]: | 6,2 |
check value: | Ece r90 approved |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Location: | Front axle |
Minimum thickness [mm]: | 25 |
Number of fixing holes: | 2 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 299 |
Surface: | Coated |
Weight, kg]: | 8.11 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 49,3 |
Hole diameter [mm]: | 14.7 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 25 |
Outside diameter [mm]: | 299 |
Surface: | Coated |
check value: | E1 90R-02C0118/0657 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 62 |
Chamfer diameter 1 [mm]: | 114.3 |
Height [mm]: | 49,3 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 26 |
Outside diameter [mm]: | 299 |
Surface: | Varnished |
check value: | E1 90R-02 C0185/0675 |
Brake disc thickness [mm]: | 28 |
Brake disc type: | Ventilated |
Centering diameter [mm]: | 62 |
Diameter [mm]: | 298,5 |
Height [mm]: | 49, 49,3 |
Minimum thickness [mm]: | 25 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 299 |
Surface: | Coated |
Brake disc thickness [mm]: | 25 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 62 |
Height [mm]: | 46 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 22 |
Outside diameter [mm]: | 282 |
Surface: | Coated |
When looking for the Brake disc for your Toyota Corolla (E210) Hatchback, keep these points in mind:
Discovering the ideal component can be achieved through various methods:
Deciding between original or alternative Brake rotor for your Toyota Corolla (E210) Hatchback involves weighing numerous factors and personal preferences. Consider these insights to guide your decision-making process:
Leading 5 brands in the "Brake rotors" category for Toyota Corolla (E210) Hatchback include:
Our selection spans a broad range within the “Brake rotor” category, with affordability from 96 to 860 PLN.
