| Length 1 [mm]: | 52,40 |
| Length 2 [mm]: | 19,50 |
| Number of grooves: | 8 |
| Outside diameter [mm]: | 50 |
| Additional Information: | Special mounting hardware required |
| Features of execution 8: | Special mounting hardware required |
| For article or original number: | 328V2-2, 357V1-1, 361V1-1, F-585322.XX |
| for manufacturer number: | 328v2-2, 357v1-1, 357v1-1, 361v1-1, 361v1-1, F-585322.xx, F-585322.xx, 328v2-2 |
| Weight, kg]: | 0.44 |
| Number of grooves: | 5 |
| Number of teeth: | 33 |
| Outside diameter [mm]: | 57 |
| Weight, kg]: | 0,4717 |
| Bolt head profile: | Torx |
| Depth [mm]: | 12.1 |
| Diameter [mm]: | 61.6 |
| Direction of rotation: | Clockwise |
| Features of execution 8: | Special mounting hardware required |
| Hole diameter [mm]: | 17 |
| Number of grooves: | 5 |
| Number of ribs: | 5 |
| Outside diameter [mm]: | 61.6 |
| Thread size: | M14 |
| Weight, kg]: | 0,65 |
| Width [mm]: | 39,2, 39.2 |
| Additional Information: | Special mounting hardware required |
| Features of execution 8: | Special mounting hardware required |
| For article or original number: | F-228751.XX |
| for manufacturer number: | F-228751.xx |
| Number of grooves: | 7 |
| Number of grooves: | 6 |
| Outside diameter [mm]: | 59 |
| Recommended special tool number: | GAT4955B, Gat4955a |
| Width [mm]: | 38 |
| Bolt head profile: | Torx |
| Depth [mm]: | 11.1 |
| Diameter [mm]: | 54.3 |
| Direction of rotation: | Clockwise |
| Features of execution 8: | Special mounting hardware required |
| Hole diameter [mm]: | 17 |
| Number of grooves: | 6 |
| Number of ribs: | 6 |
| Outside diameter [mm]: | 54.3 |
| Thread size: | M16 |
| Weight, kg]: | 0.46 |
| Width [mm]: | 33,2, 33.2 |
| Weight, kg]: | 0,5842 |
| Inner diameter [mm]: | 17 |
| Number of ribs: | 6 |
| Outside diameter [mm]: | 78 |
| Required amount: | 1 |
| Thickness [mm]: | 43 mm |
| Weight, kg]: | 0.33 |
| Direction of rotation: | Clockwise |
| distance from belt pulley to alternator [mm]: | 3, 3.4 mixing ratio |
| Features of execution 8: | With cap |
| for manufacturer number: | F-236528.xx |
| Inner diameter [mm]: | 17 |
| Installation depth [mm]: | 11.3 |
| Manufacturer limitation: | Bosch |
| Number of grooves: | 6 |
| Outside diameter [mm]: | 54, 54.1 |
| Overall length [mm]: | 31.9 |
| Pulley diameter [mm]: | 49, 49.1 |
| Thread size: | M16x1,5 |
| Width [mm]: | 31,9 |
| Length 1 [mm]: | 41 |
| Length 2 [mm]: | 10,50 |
| Number of grooves: | 7 |
| Outside diameter [mm]: | 58 |
| Additional Information: | Special mounting hardware required |
| Diameter 1 /diameter 2 [mm]: | 55,7/17,0 |
| Features of execution 8: | Special mounting hardware required |
| For article or original number: | F-557564.XX |
| for manufacturer number: | F-557564.xx |
| Number of grooves: | 5 |
| Width [mm]: | 36, 36,1 |
| Additional Information: | Special mounting hardware required |
| Diameter 1 /diameter 2 [mm]: | 58,7/17,0 |
| Features of execution 8: | Special mounting hardware required |
| For article or original number: | F-561957.XX |
| for manufacturer number: | F-561957.xx |
| Number of grooves: | 6 |
| Width [mm]: | 51 |
| Weight, kg]: | 0.41 |
| Bolt head profile: | Torx |
| Depth [mm]: | 14 |
| Diameter [mm]: | 59.8 |
| Direction of rotation: | Clockwise |
| Features of execution 8: | Special mounting hardware required |
| Hole diameter [mm]: | 17 |
| Number of grooves: | 5 |
| Number of ribs: | 5 |
| Thread size: | M14 |
| Weight, kg]: | 0.62 |
| Width [mm]: | 40,4, 40.4 |
| Additional Information: | Special mounting hardware required |
| Diameter 1 /diameter 2 [mm]: | 59,9/17,0 |
| Features of execution 8: | Special mounting hardware required |
| For article or original number: | F-240026.XX |
| for manufacturer number: | F-240026.xx |
| Number of grooves: | 6 |
| Width [mm]: | 37,8, 38 |
| Direction of rotation: | Clockwise |
| distance from belt pulley to alternator [mm]: | 15, 15.3 mixing ratio |
| Features of execution 8: | With cap |
| for manufacturer number: | F-232030.10/.11, F-239809.xx, F-553857.xx |
| Inner diameter [mm]: | 17 |
| Installation depth [mm]: | 14.5 |
| Manufacturer limitation: | Valeo |
| Number of grooves: | 5 |
| Outside diameter [mm]: | 54, 54.1 |
| Overall length [mm]: | 37.5 |
| Pulley diameter [mm]: | 49.7, 50 |
| Thread size: | M16x1,5 |
| Width [mm]: | 37,5 |
