| alternator charging current (A): | 150 |
| Belt pulley: | With multi-ribbed pulley |
| Connector version identification number: | Pl166 |
| Direction of rotation: | Clockwise |
| distance from belt pulley to alternator [mm]: | 32 |
| Generator model: | Except vacuum pump, For three-phase alternator |
| Klemma: | B+(M8),LIN |
| Length [mm]: | 185 |
| Mount type: | Double lug attachment |
| Number of grooves: | 5 |
| Pulley diameter [mm]: | 54 |
| recommended additional repairs: | V-Belt / Poly V-Belt |
| Voltage [V]: | 14 |
| alternator charging current (A): | 150 |
| Belt pulley: | With freewheel belt pulley |
| Length 1 [mm]: | 29 |
| Length 2 [mm]: | 13,50 |
| Length 3 [mm]: | 61 |
| Voltage [V]: | 12 |
| alternator charging current (A): | 150, 150 A |
| Belt pulley: | With multi-ribbed pulley |
| Connector version identification number: | 0238, LIN 2 (PLUG 238) |
| Hole diameter 1 [mm]: | 8 |
| Hole diameter 2 [mm]: | 8 |
| Klemma: | LIN 2, M8 b+ |
| Length 1 [mm]: | 33 |
| Length 2 [mm]: | 33 |
| Length 3 [mm]: | 52 |
| Number of ribs: | 5 |
| Onboard network model: | For a vehicle with a 12V on-board network |
| Pulley diameter [mm]: | 54 |
| Thickness 1 [mm]: | 15 |
| Voltage [V]: | 12 |
| alternator charging current (A): | 150 |
| Belt pulley: | With freewheel belt pulley |
| Number of ribs: | 5 |
| Voltage [V]: | 12 |
| alternator charging current (A): | 150 |
| Belt pulley: | With belt pulley |
| Length 1 [mm]: | 32 |
| Length 2 [mm]: | 14,50 |
| Length 3 [mm]: | 52 |
| Voltage [V]: | 12 |
| alternator charging current (A): | 150 |
| Belt pulley: | with ribbed V-belt pulley |
| Number of ribs: | 5 |
| Pulley diameter [mm]: | 54 |
| Voltage [V]: | 14 |
| alternator charging current (A): | 150, 150 A |
| Belt pulley: | With multi-ribbed pulley |
| Connector version identification number: | Lin, Pl125 |
| Direction of rotation: | Clockwise |
| Number of grooves: | 5 |
| Pulley diameter [mm]: | 54 |
| Voltage [V]: | 14 |
| alternator charging current (A): | 175 |
| Belt pulley: | With freewheel belt pulley |
| Connector version identification number: | Pl166 |
| Direction of rotation: | Clockwise |
| distance from belt pulley to alternator [mm]: | 30 |
| Generator model: | Except vacuum pump |
| Klemma: | B+(M8),LIN |
| Length [mm]: | 195 |
| Mount type: | Double lug attachment |
| Number of grooves: | 6 |
| Pulley diameter [mm]: | 55 |
| Voltage [V]: | 14 |
| alternator charging current (A): | 175 |
| Belt pulley: | With freewheel belt pulley |
| Length 1 [mm]: | 29 |
| Length 2 [mm]: | 14,00 |
| Length 3 [mm]: | 60 |
| Voltage [V]: | 12 |
| alternator charging current (A): | 150 |
| Belt pulley: | With freewheel belt pulley |
| Pulley diameter [mm]: | 50 |
| Voltage [V]: | 14 |
| alternator charging current (A): | 150 |
| Belt pulley: | With freewheel belt pulley |
| Number of ribs: | 5 |
| Pulley diameter [mm]: | 53 |
| Voltage [V]: | 14 |
