Belt pulley: | With freewheel belt pulley |
Connector version identification number: | Pl72 |
Direction of rotation: | Clockwise |
Generator model: | Except vacuum pump, For three-phase alternator |
Klemma: | B+(M8),L,DFM |
Length [mm]: | 189 |
Mount type: | Double lug attachment |
Number of grooves: | 6 |
Pulley diameter [mm]: | 56 |
Rated voltage [V]: | 14 |
Voltage [V]: | 14 |
alternator charging current (A): | 110, 110 A |
distance from belt pulley to alternator [mm]: | 39 |
recommended additional repairs: | V-Belt / Poly V-Belt |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | Pl124 |
Direction of rotation: | Clockwise |
Generator model: | Except vacuum pump, For three-phase alternator |
Klemma: | B2+(M8), Com |
Length [mm]: | 190 |
Mount type: | Double lug attachment |
Number of grooves: | 7 |
Pulley diameter [mm]: | 54.8 |
Rated voltage [V]: | 14 |
Voltage [V]: | 14 |
alternator charging current (A): | 90, 90 A |
distance from belt pulley to alternator [mm]: | 32,5 |
recommended additional repairs: | V-Belt / Poly V-Belt |
Belt pulley: | With belt pulley |
Length 1 [mm]: | 50, 52.5 |
Length 2 [mm]: | 28 |
Length 3 [mm]: | 46 |
Voltage [V]: | 12 |
alternator charging current (A): | 60, 60 A |
Voltage [V]: | 14 |
alternator charging current (A): | 60 |
Belt pulley: | With belt pulley |
Length 1 [mm]: | 46 |
Length 2 [mm]: | 27, 27,00 |
Length 3 [mm]: | 67, 68 |
Voltage [V]: | 12 |
alternator charging current (A): | 75, 75 A |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+SIGLP |
Direction of rotation: | Clockwise |
Number of fixing holes: | 3 |
Number of grooves: | 4 |
Pulley diameter [mm]: | 60 |
Voltage [V]: | 14 |
alternator charging current (A): | 75 |
distance from belt pulley to alternator [mm]: | 52 |
Additional Information: | With built-in regulator |
Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
Connector version identification number: | CPA0167 |
Features of version 2: | Cal12104as |
Number of fixing holes: | 3 |
Number of ribs: | 4 |
Number of threaded holes: | 1 |
Pulley diameter [mm]: | 60 |
Quality: | Brand new series |
Voltage [V]: | 12 |
alternator charging current (A): | 75, 75 A |
Belt pulley: | With freewheel belt pulley |
Length 1 [mm]: | 37.5 |
Length 2 [mm]: | 14,00 |
Length 3 [mm]: | 60.5 |
Voltage [V]: | 12 |
alternator charging current (A): | 125 |
Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
Connector version identification number: | Com |
Current [A]: | 90 |
Direction of rotation: | Clockwise |
Klemma: | B+ m8 |
Number of ribs: | 7 |
Pulley diameter [mm]: | 55 |
Voltage [V]: | 12 |
alternator charging current (A): | 90 |
Additional Information: | With built-in regulator |
Belt pulley: | With belt pulley |
Connector version identification number: | CPA0090 |
Features of version 2: | Cal30119as |
Quality: | Brand new series |
Voltage [V]: | 12 |
alternator charging current (A): | 65, 65 A |
Belt pulley: | Toothed belt pulley |
Number of grooves: | 4 |
Voltage [V]: | 12 |
alternator charging current (A): | 75 |
Belt pulley: | With freewheel belt pulley |
Connector version identification number: | 0129, L-dfm plug 129 |
Hole diameter 1 [mm]: | 9 |
Klemma: | L-DFM, M8 b+ |
Length 1 [mm]: | 39 |
Length 3 [mm]: | 61 |
Number of ribs: | 6 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 55 |
Thickness 1 [mm]: | 14 |
Voltage [V]: | 14 |
alternator charging current (A): | 110, 110 A |
Belt pulley: | With freewheel belt pulley |
Connector version identification number: | 0129, L-dfm plug 129 |
Hole diameter 1 [mm]: | 9 |
Klemma: | L-DFM, M8 b+ |
Length 1 [mm]: | 39 |
Length 3 [mm]: | 61 |
Number of ribs: | 6 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 55 |
Thickness 1 [mm]: | 14 |
Voltage [V]: | 14 |
alternator charging current (A): | 110, 110 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | Pl122 |
Diameter [mm]: | 59.5 |
Direction of rotation: | Clockwise |
Generator model: | Except vacuum pump |
Number of grooves: | 4 |
Pulley diameter [mm]: | 59.5 |
Voltage [V]: | 14 |
alternator charging current (A): | 75, 75 A |
Length 1 [mm]: | 38.5 |
Length 2 [mm]: | 14,00 |
Length 3 [mm]: | 61.5 |
Voltage [V]: | 12 |
alternator charging current (A): | 120 |
Belt pulley: | Without belt pulley |
Length 1 [mm]: | 36 |
Length 2 [mm]: | 14, 14,00 |
Length 3 [mm]: | 61, 61.5 |
Voltage [V]: | 12 |
alternator charging current (A): | 125, 125 A |
Belt pulley: | With belt pulley |
Length 1 [mm]: | 54 |
Length 2 [mm]: | 27, 27,00 |
Length 3 [mm]: | 65.5, 66 |
Voltage [V]: | 12 |
alternator charging current (A): | 75, 75 A |
Belt pulley: | With belt pulley |
Length 1 [mm]: | 42 |
Length 2 [mm]: | 15, 15,00 |
Length 3 [mm]: | 57, 59 |
Voltage [V]: | 12 |
alternator charging current (A): | 110, 110 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0084, L-D (Plug84) |
Klemma: | L-D Plug84, M8 b+ |
Length 1 [mm]: | 54 |
Length 2 [mm]: | 54 |
Length 3 [mm]: | 68 |
Number of ribs: | 3 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 60 |
Thread size: | M10 |
Thread type: | With internal thread |
Voltage [V]: | 14 |
alternator charging current (A): | 70, 70 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0182, Com (Plug 182) |
Hole diameter 1 [mm]: | 9 |
Klemma: | Com, M8 b+ |
Length 1 [mm]: | 33.5 |
Length 2 [mm]: | 33.5 |
Length 3 [mm]: | 60.5 |
Number of ribs: | 7 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 55 |
Voltage [V]: | 14 |
alternator charging current (A): | 90, 90 A |
