Belt pulley: | With multi-ribbed pulley |
Number of ribs: | 5 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 57.5 |
Quality: | Oe |
Rated voltage [V]: | 14 |
Voltage [V]: | 14 |
alternator charging current (A): | 80, 80 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0203, L-ig-rlo-m plug 203 |
Hole diameter 1 [mm]: | 10 |
Klemma: | L-IG-RLO-M, M6 b+ |
Length 1 [mm]: | 48 |
Length 2 [mm]: | 58 |
Length 3 [mm]: | 36.5 |
Number of ribs: | 5 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 57 |
Voltage [V]: | 14 |
alternator charging current (A): | 80, 80 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0203, L-ig-rlo-m plug 203 |
Hole diameter 1 [mm]: | 10 |
Klemma: | L-IG-RLO-M, M6 b+ |
Length 1 [mm]: | 48 |
Length 2 [mm]: | 58 |
Length 3 [mm]: | 36.5 |
Number of ribs: | 5 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 57 |
Voltage [V]: | 14 |
alternator charging current (A): | 80, 80 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0203 |
Hole diameter 1 [mm]: | 10 |
Klemma: | L-IG-RLO-M, M6 b+ |
Number of ribs: | 5 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 52 |
Voltage [V]: | 14 |
alternator charging current (A): | 80 |
Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
Connector version identification number: | CPA0328 |
Features of version 2: | Cal40423gs |
Klemma: | M6 b+ |
Number of ribs: | 5 |
Pulley diameter [mm]: | 57 |
Quality: | Genuine series |
Voltage [V]: | 12 |
alternator charging current (A): | 80, 80 A |
Belt pulley: | With freewheel belt pulley |
Direction of rotation: | Clockwise |
Number of ribs: | 6 |
Voltage [V]: | 12 |
alternator charging current (A): | 115 |
Number of grooves: | 6 |
Voltage [V]: | 12 |
alternator charging current (A): | 70, 70 A |
Belt pulley: | With multi-ribbed pulley |
Connector version identification number: | 0203 |
Hole diameter 1 [mm]: | 10 |
Klemma: | L-IG-RLO-M, M6 b+ |
Number of ribs: | 5 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 52 |
Voltage [V]: | 14 |
alternator charging current (A): | 80 |
Belt pulley: | With freewheel belt pulley |
Connector version identification number: | L / IG / S / M, L-ig-s-m |
Direction of rotation: | Clockwise |
Klemma: | B+ m6 |
Number of ribs: | 6 |
Onboard network model: | For a vehicle with a 12V on-board network |
Pulley diameter [mm]: | 52 |
Voltage [V]: | 12 |
alternator charging current (A): | 100, 100 A |
Additional Information: | With built-in regulator |
Belt pulley: | With ribbed V-belt pulley |
Voltage [V]: | 12 |
alternator charging current (A): | 100 A |
Belt pulley: | With ribbed V-belt pulley, with ribbed V-belt pulley |
Connector version identification number: | CPA0328 |
Features of version 2: | Cal40460gs |
Number of ribs: | 5 |
Pulley diameter [mm]: | 52 |
Quality: | Genuine series |
Voltage [V]: | 12 |
alternator charging current (A): | 80, 80 A |
Voltage [V]: | 12 |
alternator charging current (A): | 80 |
