Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+L |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 4 |
Pulley diameter [mm]: | 58 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 40 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+SIGLP |
Direction of rotation: | Clockwise |
Number of fixing holes: | 3 |
Number of grooves: | 4 |
Pulley diameter [mm]: | 60 |
Voltage [V]: | 14 |
alternator charging current (A): | 75 |
distance from belt pulley to alternator [mm]: | 52 |
Connector version identification number: | B+D+W |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 1 |
Pulley diameter [mm]: | 64 |
Voltage [V]: | 14 |
alternator charging current (A): | 55 |
distance from belt pulley to alternator [mm]: | 37 |
Connector version identification number: | B+D+W |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 1 |
Pulley diameter [mm]: | 65 |
Voltage [V]: | 14 |
alternator charging current (A): | 70 |
distance from belt pulley to alternator [mm]: | 30 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+DP |
Direction of rotation: | Clockwise |
Number of fixing holes: | 3 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 49 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 84,5 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+LDF |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 49 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 51 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+D+ |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 5 |
Pulley diameter [mm]: | 54 |
Voltage [V]: | 14 |
alternator charging current (A): | 70 |
distance from belt pulley to alternator [mm]: | 24 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+IGL |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 4 |
Pulley diameter [mm]: | 45 |
Voltage [V]: | 14 |
alternator charging current (A): | 45 |
distance from belt pulley to alternator [mm]: | 38 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+LDF |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 48 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 53 |
Connector version identification number: | B+LR |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 1 |
Pulley diameter [mm]: | 69 |
Voltage [V]: | 14 |
alternator charging current (A): | 70 |
distance from belt pulley to alternator [mm]: | 42 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+CSL |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 5 |
Pulley diameter [mm]: | 55 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 52 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+LDFM |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 49 |
Voltage [V]: | 14 |
alternator charging current (A): | 125 |
distance from belt pulley to alternator [mm]: | 42 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+LDFM |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 56 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 48 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+FR-SIG-A |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 53 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 49 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+MIGL |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 55 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 57 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+D+W |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 50 |
Voltage [V]: | 14 |
alternator charging current (A): | 90 |
distance from belt pulley to alternator [mm]: | 49 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+L |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 7 |
Pulley diameter [mm]: | 55 |
Voltage [V]: | 14 |
alternator charging current (A): | 110 |
distance from belt pulley to alternator [mm]: | 52 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+L,DFM |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 65 |
Voltage [V]: | 14 |
alternator charging current (A): | 120 |
distance from belt pulley to alternator [mm]: | 39 |
Belt pulley: | With freewheel belt pulley |
Connector version identification number: | B+LF |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 54 |
Voltage [V]: | 14 |
alternator charging current (A): | 120 |
distance from belt pulley to alternator [mm]: | 61 |
Belt pulley: | with ribbed V-belt pulley |
Connector version identification number: | B+LIG |
Direction of rotation: | Clockwise |
Number of fixing holes: | 2 |
Number of grooves: | 6 |
Pulley diameter [mm]: | 50 |
Voltage [V]: | 14 |
alternator charging current (A): | 120 |
distance from belt pulley to alternator [mm]: | 78 |
