Additional Information: | With bracket |
Connection technique: | 4 x 2,8 mm, 5 x 6,3 mm |
Features of version 2: | A |
Number of poles: | 9 |
Plug version: | Flat plug holder |
Connection technique: | 5 x 6,3 mm |
Features of execution 8: | With fixing head |
Number of poles: | 5 |
Plug version: | Flat plug holder |
Combination switch functions: | Changeover device |
Connection technique: | 2 x 6,3 mm, 3 x 4,8 mm |
Current [A]: | 20, 25 |
Features of execution 8: | With resistance |
Height [mm]: | 26 |
Number of poles: | 5 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Relay function: | Working contact |
Relay type: | Universal relays |
Switch number: | 404 |
Up to temperature range [° C]: | +80, 80 |
Connection technique: | 2 x 6,3 mm, 3 x 4,8 mm |
Number of poles: | 5 |
Plug version: | Flat plug holder |
Relay type: | Universal relays |
Combination switch functions: | Make contact device |
Connection technique: | 2 x 6,3 mm, 2 x 9,5 mm |
Current [A]: | 70 |
Features of execution 8: | With resistance, With switch |
Height [mm]: | 25,1, 25.1 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Relay type: | Universal relays |
Switch number: | 614 |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 4 x 6,3 mm |
Current [A]: | 40 |
Features of execution 8: | With resistance, With switch |
Height [mm]: | 21,5, 21.5 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Relay function: | Working contact |
Relay type: | Universal relays |
Switch number: | 645 |
Up to temperature range [° C]: | +80, 80 |
Voltage [V]: | 12 |
Weight, kg]: | 0.039 |
Combination switch functions: | Changeover device |
Connection technique: | 5 x 6,3 mm |
Current [A]: | 10, 20 |
Features of execution 8: | With switch |
Height [mm]: | 21,5, 21.5 |
Number of poles: | 5 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 5 x 6,3 mm |
Current [A]: | 40 |
Features of execution 8: | With resistance, With switch |
Height [mm]: | 21,5, 21.5 |
Number of poles: | 5 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Up to temperature range [° C]: | +85, 85 |
Combination switch functions: | Make contact device |
Connection technique: | 1 x 2,8 mm, 3 x 6,3 mm |
Current [A]: | 15 |
Features of execution 8: | With resistance |
Height [mm]: | 30 |
Number of poles: | 4 |
Rated voltage [V]: | 12 |
Relay type: | Universal relays |
Switch number: | 109 |
Up to temperature range [° C]: | +70, 70 |
Combination switch functions: | Changeover device |
Connection technique: | 2 x 6,3 mm, 3 x 4,8 mm |
Current [A]: | 10, 20 |
Features of execution 8: | With diode |
Height [mm]: | 26 |
Number of poles: | 5 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 4 x 6,3 mm |
Current [A]: | 30 |
Features of execution 8: | With switch |
Height [mm]: | 21.5, 25,7 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +85, 85 |
Combination switch functions: | Make contact device |
Connection technique: | 4 x 6,3 mm |
Current [A]: | 20 |
Features of execution 8: | With switch |
Height [mm]: | 21,5, 21.5 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Combination switch functions: | Changeover device |
Connection technique: | 2 x 6,3 mm, 3 x 4,8 mm |
Current [A]: | 10, 5 |
Height [mm]: | 26 |
Number of poles: | 5 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +110, 110 |
Current [A]: | 30 |
Height [mm]: | 35 |
Number of poles: | 5 |
Up to temperature range [° C]: | +85 |
Voltage [V]: | 12 |
Weight, kg]: | 29 |
Combination switch functions: | Make contact device |
Connection technique: | 4 x 6,3 mm |
Current [A]: | 20 |
Features of execution 8: | With resistance, With switch |
Height [mm]: | 25 |
Number of poles: | 4 |
Plug version: | Flat plug |
Protection type (IP code): | Ip 67 |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 4 x 6,3 mm |
Current [A]: | 15 |
Features of execution 8: | With protection, With switch |
Height [mm]: | 21 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 2 x 6,3 mm, 2 x 9,5 mm |
Current [A]: | 70 |
Features of execution 8: | With resistance, With switch |
Height [mm]: | 39,8, 39.8 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Combination switch functions: | Make contact device |
Connection technique: | 2 x 6,3 mm, 2 x 9,5 mm |
Current [A]: | 40 |
Features of execution 8: | With switch |
Height [mm]: | 25 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 24 |
Relay type: | Universal relays |
Up to temperature range [° C]: | +80, 80 |
Current [A]: | 40 |
Number of poles: | 5 |
Up to temperature range [° C]: | +85 |
Voltage [V]: | 12 |
Weight [g]: | 27 |
Combination switch functions: | Make contact device |
Connection technique: | 2 x 6,3 mm, 2 x 9,5 mm |
Current [A]: | 70 |
Features of execution 8: | With diode, With switch |
Height [mm]: | 38,5, 38.5 |
Number of poles: | 4 |
Plug version: | Flat plug |
Rated voltage [V]: | 12 |
