Additional Information: | With screws |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Diameter [mm]: | 320 |
Height [mm]: | 48,5, 49 |
Minimum thickness [mm]: | 21.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 320 |
Surface: | Coated |
Treatment: | High carbon |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Twin brake discs, Ventilated |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 49,0 |
Hole diameter [mm]: | 15.3 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 21.4 |
Outside diameter [mm]: | 320 |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
check value: | E1 90R-02C0679/1104 |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Ventilated |
Height [mm]: | 66,5 |
Hub diameter [mm]: | 69 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 29.4 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 342 |
Surface: | Coated |
Weight, kg]: | 11.65 |
Arrangement / number of holes: | 6/5 |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Twin brake discs, Ventilated, With internal ventilation |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 62 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 29.4 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 342 |
Quality: | Stahl-Topf/Steel hub |
Surface: | Coated |
Treatment: | High carbon |
Weight, kg]: | 10.8 |
check value: | Ece r90 approved |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Twin brake discs, Ventilated |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 62,5 |
Hole diameter [mm]: | 15.3 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 29.4 |
Outside diameter [mm]: | 342 |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
check value: | E1 90R-02C0679/1102 |
Additional Information: | With screws |
Brake disc thickness [mm]: | 26 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Diameter [mm]: | 360 |
Height [mm]: | 48,5, 49 |
Minimum thickness [mm]: | 23.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | High carbon |
Additional Information: | With screws |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Diameter [mm]: | 342 |
Height [mm]: | 62,5, 63 |
Minimum thickness [mm]: | 29.4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 342 |
Surface: | Coated |
Treatment: | High carbon |
Brake disc thickness [mm]: | 32 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 62,8 |
Minimum thickness [mm]: | 29.4 |
Outside diameter [mm]: | 342 |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
complies with EEC standards: | ECE-R90 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 48,8 |
Minimum thickness [mm]: | 21.4 |
Outside diameter [mm]: | 320 |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
complies with EEC standards: | ECE-R90 |
Additional Information: | With screws |
Brake disc thickness [mm]: | 36 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Diameter [mm]: | 360 |
Height [mm]: | 62,5, 63 |
Minimum thickness [mm]: | 34 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | High carbon |
Brake disc thickness [mm]: | 36 |
Brake disc type: | Perforated, Ventilated |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 62,8 |
Minimum thickness [mm]: | 34 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | Alloyed / High Carbon |
complies with EEC standards: | ECE-R90 |
Arrangement / number of holes: | 7/5 |
Brake disc thickness [mm]: | 26 |
Brake disc type: | Slotted / Perforated, Ventilated, With internal ventilation |
Centering diameter [mm]: | 67 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 48 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 24 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | High carbon |
Weight, kg]: | 11 |
check value: | Ece r90 approved |
Additional Information: | With screws |
Brake disc thickness [mm]: | 26 |
Brake disc type: | Notched, Ventilated |
Centering diameter [mm]: | 67 |
Diameter [mm]: | 360 |
Height [mm]: | 48 |
Minimum thickness [mm]: | 24 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | High carbon |
Brake disc thickness [mm]: | 36 |
Brake disc type: | Ventilated, With internal ventilation |
Centering diameter [mm]: | 67 |
Height [mm]: | 64,5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 33 |
Outside diameter [mm]: | 390 |
Surface: | Coated |
Treatment: | High carbon |
Arrangement / number of holes: | 7/5 |
Brake disc thickness [mm]: | 36 |
Brake disc type: | Notched, Perforated, Ventilated |
Centering diameter [mm]: | 67 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 64 |
Minimum thickness [mm]: | 33 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 390 |
Quality: | Alu hub floating, Alu-Topf schwimmend |
Surface: | Coated |
Weight, kg]: | 14.8 |
check value: | Ece r90 approved |
Brake disc thickness [mm]: | 36 |
Brake disc type: | Twin brake discs, Ventilated, With internal ventilation |
Location: | Front axle |
Location in the car: | Left, Right |
Outside diameter [mm]: | 390 |
Brake disc thickness [mm]: | 24 |
Brake disc type: | With internal ventilation |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Location: | Rear axle |
Minimum thickness [mm]: | 21.4 |
Number of fixing holes: | 1 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 320 |
Surface: | Coated |
Treatment: | High carbon |
Weight, kg]: | 8 |
Brake disc thickness [mm]: | 32 |
Brake disc type: | With internal ventilation |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Location: | Front axle |
Minimum thickness [mm]: | 29.4 |
Number of fixing holes: | 1 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 330 |
Surface: | Coated |
Treatment: | High carbon |
Weight, kg]: | 10.5 |
Brake disc thickness [mm]: | 26 |
Brake disc type: | With internal ventilation |
Centering diameter [mm]: | 69 |
Chamfer diameter 1 [mm]: | 112 |
Location: | Rear axle |
Minimum thickness [mm]: | 23.4 |
Number of fixing holes: | 1 |
Number of holes in the wheel rim: | 5 |
Outside diameter [mm]: | 360 |
Surface: | Coated |
Treatment: | High carbon |
Weight, kg]: | 10.4 |
