Location: | Front axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 38.9, 39 |
Hub bore diameter [mm]: | 65 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 10 mm |
Weight, kg]: | 3 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 35, 35.2 |
Hub bore diameter [mm]: | 65 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 12 mm |
Weight, kg]: | 3.2 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 6/5 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 38.7, 39 |
Hub bore diameter [mm]: | 65 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 6 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 10 mm |
Weight, kg]: | 2.99 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 39, 39.4 |
Hub bore diameter [mm]: | 65 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 232 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 9 mm |
Weight, kg]: | 2.64 |
check value: | Ece r90 approved |
Location: | Front axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Arrangement / number of holes: | 7/4 |
Brake disc thickness [mm]: | 11 |
Brake disc type: | Full |
Centering diameter [mm]: | 60 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 41 |
Hub bore diameter [mm]: | 60 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 7 |
Outside diameter [mm]: | 240 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 11 mm |
Weight, kg]: | 3.28 |
check value: | Ece r90 approved |
Location: | Front axle |
Location in the car: | Left, Right |
Part type: | Brake disc |
Arrangement / number of holes: | 6/4 |
Brake disc thickness [mm]: | 11 |
Brake disc type: | Full |
Centering diameter [mm]: | 59 |
Chamfer diameter 1 [mm]: | 98 |
Height [mm]: | 40 |
Hub bore diameter [mm]: | 59 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 9.2 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 6 |
Outside diameter [mm]: | 240 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 11 mm |
Weight, kg]: | 3,6 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 33.9, 34 |
Hub bore diameter [mm]: | 65 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 10 mm |
Weight, kg]: | 2,9 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 7/4 |
Brake disc type: | Full |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 41 |
Hub bore diameter [mm]: | 60 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of mounting holes: | 7 |
Outside diameter [mm]: | 256 |
Part type: | Brake disc |
Thickness [mm]: | 11 mm |
Weight, kg]: | 3,8 |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 57 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 42 |
Hub bore diameter [mm]: | 57 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 240 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 10 mm |
Treatment: | High carbon |
Weight, kg]: | 3 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 4/4 |
Brake disc thickness [mm]: | 10 |
Brake disc type: | Full |
Centering diameter [mm]: | 68 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 59.5, 60 |
Hub bore diameter [mm]: | 68 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 8 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 245 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 10 mm |
Weight, kg]: | 3,5 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 4/4 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 64 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 43 |
Hub bore diameter [mm]: | 63.5 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 239.5, 240 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 12 mm |
Weight, kg]: | 3.59 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 6/5 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 40.6, 41 |
Hub bore diameter [mm]: | 65 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 6 |
Outside diameter [mm]: | 230 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 9 mm |
Weight, kg]: | 2.62 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 4/4 |
Brake disc thickness [mm]: | 13 |
Brake disc type: | Full |
Centering diameter [mm]: | 68 |
Chamfer diameter 1 [mm]: | 108 |
Height [mm]: | 46.5, 47 |
Hub bore diameter [mm]: | 68 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 11 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 4 |
Outside diameter [mm]: | 257 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 13 mm |
Weight, kg]: | 4,3 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 5/4 |
Brake disc thickness [mm]: | 13 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 39, 39.2 |
Hub bore diameter [mm]: | 65 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 11 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 5 |
Outside diameter [mm]: | 256 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 13 mm |
Weight, kg]: | 4,2 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 6/4 |
Brake disc thickness [mm]: | 12 |
Brake disc type: | Full |
Centering diameter [mm]: | 61 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 41 |
Hub bore diameter [mm]: | 61 |
Location: | Front axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 10.5 |
Number of holes in the wheel rim: | 4 |
Number of mounting holes: | 6 |
Outside diameter [mm]: | 238 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 12 mm |
Weight, kg]: | 3.51 |
check value: | Ece r90 approved |
Arrangement / number of holes: | 7/5 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 67 |
Chamfer diameter 1 [mm]: | 112 |
Height [mm]: | 55.5, 56 |
Hub bore diameter [mm]: | 67 |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7.3 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 7 |
Outside diameter [mm]: | 258 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 9 mm |
Weight, kg]: | 3.2 |
Arrangement / number of holes: | 6/5 |
Brake disc thickness [mm]: | 9 |
Brake disc type: | Full |
Centering diameter [mm]: | 65 |
Chamfer diameter 1 [mm]: | 100 |
Height [mm]: | 33.5, 34 |
Hub bore diameter [mm]: | 65 |
Location: | Rear axle |
Location in the car: | Left, Right |
Minimum thickness [mm]: | 7 |
Number of holes in the wheel rim: | 5 |
Number of mounting holes: | 6 |
Outside diameter [mm]: | 239 |
Part type: | Brake disc |
Surface: | Coated |
Thickness [mm]: | 9 mm |
Weight, kg]: | 2.68, 2.7 |
check value: | Ece r90 approved |
